Milestone Achieved: Breakthrough Of Tunnel-2, The Longest Tunnel On Mumbai Suburban Railway Network

Milestone Achieved: Breakthrough Of Tunnel-2, The Longest Tunnel On Mumbai Suburban Railway Network

The Mumbai Railway Vikas Corporation (MRVC) proudly announces the successful breakthrough of Tunnel-2 (Wavarle Tunnel), the longest tunnel in the Mumbai Suburban Railway Network, as part of the Panvel-Karjat railway project under the Mumbai Urban Transport Project 3 (MUTP-3).

Kamal MishraUpdated: Friday, June 07, 2024, 06:27 PM IST
article-image
Milestone Achieved: Breakthrough Of Tunnel-2, The Longest Tunnel On Mumbai Suburban Railway Network |

Mumbai, June 7: The Mumbai Railway Vikas Corporation (MRVC) proudly announces the successful breakthrough of Tunnel-2 (Wavarle Tunnel), the longest tunnel in the Mumbai Suburban Railway Network, as part of the Panvel-Karjat railway project under the Mumbai Urban Transport Project 3 (MUTP-3).

Project Overview

The Panvel-Karjat railway project encompasses the construction of three tunnels, totalling 3164 meters in length:

Tunnel-1 (Nadhal Tunnel): 219 meters

Tunnel-2 (Wavarle Tunnel): 2625 meters

Tunnel-3 (Kirawali Tunnel): 320 meters

Milestone Achievement

The underground excavation of the Wavarle Tunnel commenced on February 22, 2023. Today, on June 7, 2024, the breakthrough was achieved in the presence of MRVC's Chairman and Managing Director Shri. Subhash Chand Gupta, Director (Projects) Shri. R.K. Srivastava, ED (Tech) Shri. Vilas Wadekar, CVO Shri. B.K. Gangte, GM (Civil) Shri. Vinod Bhangale, and other key personnel involved in the project's construction. This significant achievement marks a major step forward in the project's execution despite logistical challenges and complex geological conditions.

Construction Methodology

The Wavarle Tunnel's construction adhered to the New Austrian Tunnelling Method (NATM), which involves a cyclic sequence of excavation followed by the installation of a primary support and a delayed secondary lining. Key aspects include:

Primary Lining: Shotcrete reinforced by wire mesh and rock bolts for immediate support and stability.

Excavation Technique: Drill and Blast with Observation methodology using instrumentation and 3D monitoring.

Tunnel Specifications

The Wavarle Tunnel features a ballast-less track and includes public refuge areas, a Tunnel control system (SCADA), lighting system, firefighting system, and ventilation systems meeting contemporary international standards. Additional specifications are:

Height: 7.323 meters

Width at Rail Level: 13.282 meters

Finished Cross-Sectional Area: 89.99 sqm

Gradients: R 1 in 254.623 & F 1 in 243.668

Degree of Curvature: 1-D (One Degree) with a curve length of 805 meters

Challenges and Achievements

During the excavation, significant challenges were encountered, including fractured rock masses with water seepage and minimal cover (as low as 12 meters). Two water streams cross the tunnel alignment at the low cover zone. Despite these challenges, an average underground excavation output of 175 meters per month was achieved through meticulous planning, with two rounds of blasting per day during the daytime as night time blasting is not allowed.

Collaborative Efforts

The project saw collaboration between several entities:

Technology Partner: CSIR-CIMFR guided the rock blasting process.

Design and Drawing Works: M/s AECOM

General Consultant: M/s RODIC-ARTELA (JV)

Executing Agency: M/s SDPL-TIPL-JMMIPL (JV), leveraging state-of-the-art technology and expertise.

A GIS-based project management system was implemented to monitor progress effectively.

Future Prospects

The successful breakthrough of Tunnel-2 represents a major milestone in the Panvel-Karjat railway project, paving the way for enhanced connectivity and transportation efficiency in the Mumbai suburban region.

Panvel-Karjat New Suburban Corridor:

Sanctioned Cost - 2782 cr

Progress: Physical: 50%

Target for Completion: December 2025
